Wholesale 160 kVA Diesel Generator
Wholesale 160 kva diesel generator DIESEL ENGINEBrand: Cummins(DCEC)Model:6CTA8.3-G2Type: Four strokes,Direct spurting typeCooling way: Water cooling With Type: Inline typeBore *Trip :114mm*135mmDisplacement 8.3LLubricating oil capacity: 24 LCylinder:6 cylindersRotating speed: 1500r/min or 18......
Send Inquiry
Product Description
Wholesale 160 kva diesel generator
Remarks:
1). Above Gensets are based on 50HZ,1500 RPM, 400/230V, and other special voltage can be satisfied.
2). Above Models' prime power marked "/" means the gensets to be used as standby/emergency power.
3). Engines with "QS" Series are with electric injection system.
4). Engine KTA19-G3A can be double use for both 50HZ and 60HZ, namely can be switched between 50HZ and 60HZ.
5). Requirements for Soundproof Canopy, ATS, Synchronizing Parallel Control panels etc are optional.
6). Please email us for more detail data for engines, alternators and control systems.
| DIESEL ENGINE | |
| Brand: | Cummins(DCEC) |
| Model: | 6CTA8.3-G2 |
| Type: | Four strokes,Direct spurting type |
| Cooling way: | Water cooling |
| With Type: | Inline type |
| Bore *Trip : | 114mm*135mm |
| Displacement | 8.3L |
| Lubricating oil capacity: | 24 L |
| Cylinder: | 6 cylinders |
| Rotating speed: | 1500r/min or 1800r/min |
| The regulation of rotating speed: | Electronic Governor |
| Starting way: | DC24V starting with electricity |
| AC ALTERNATOR | |
| Brand: | Stamford |
| Model: | UCI274H |
| Type: | brushless (AVR automatic voltage regulating) |
| The connecting way of the phase: | three phases four lines |
| Insulation degree: | H degree |
| Grading Protection: | IP23 |
| DIGITAL CONTROL SYSTEM |
| The control system use ComAp or Deepsea as controller, with active power, three-phase voltage, frequency and three-phase current, kilowatt-hour, power factor, oil pressure, coolant temperature, speed units, operating hours, battery voltage and other shows. Diesel engine over speed alarm and shutdown, low oil pressure alarm and shutdown, high temperature alarm and shutdown, over or low voltage alarm and shutdown, frequency too high or too low alarm and shutdown, And short-circuit protection. |
| GENSET SPECIFICATION | |
| Fuel Consumption | 0.235 L/Kw.h @ 100% Load |
| Length | 2400 mm |
| Width | 970 mm |
| Height | 1500 mm |
| Weight | 1600 kg |
| Base Fuel Tank | 8-10 Hours (Optional) |
| Soundproof Enclosure | 68db in 7 meters (Optional) |
| Automatic Transfer Switch | 300A (Optional) |
| Genset Power | 160 Kw / 200 Kva |
| Genset Voltage | 220V-440V (Adjustable) |
Remarks:
1). Above Gensets are based on 50HZ,1500 RPM, 400/230V, and other special voltage can be satisfied.
2). Above Models' prime power marked "/" means the gensets to be used as standby/emergency power.
3). Engines with "QS" Series are with electric injection system.
4). Engine KTA19-G3A can be double use for both 50HZ and 60HZ, namely can be switched between 50HZ and 60HZ.
5). Requirements for Soundproof Canopy, ATS, Synchronizing Parallel Control panels etc are optional.
6). Please email us for more detail data for engines, alternators and control systems.
